High Quality LED Machine Signal light ONN-M4S
2016 Cheap Quality LED Freezer Tube Light ONN-X08B
MOQ :50 piece
Lead Time :7 Days
Seller Support : Trade Authenticity Guaranteed & Accepting
Payment : L/C,T/T,Western Union,Pay Pal
Departure Port : Shenzhen
Product details
Supply Ability
- Supply Ability:20000 piecesWarranty(Year):2 Year
Product Specifications
- Brand name:ONN
Product Description
LED FREEZER LIGHT X08B PARAMETERS
ONN-X08B LED Freezer light /Cooler light/Refrigerator light.
Product Code | Power | Voltage | Lux | Luminous Effeciency | CCT | Size(D*L) |
ONN-X08B-C1-600-8W(FW) | 8W | 220V | 700Lm | 95-105Lm/W | 5500-6000k | ¢26.5*565mm |
ONN-X08B-C1-900-12W(FW) | 12W | 220V | 1050Lm | 95-105Lm/W | 5500-6000k | ¢26.5*869mm |
ONN-X08B-C1-1200-16W(FW) | 16W | 220V | 1500Lm | 95-105Lm/W | 4000-4500k | ¢26.5*1174mm |
ONN-X08B-C1-1500-20W(FW) | 20W | 220V | 1800Lm | 95-105Lm/W | 4000-4500k | ¢26.5*1473mm |
LED FREEZER LIGHT PRODUCT PICTURES
refrigerator led lighting: High bright SMD2835 LED chips, 93% light efficiency, 50000 hrs life time.
ONN X08B's refrigerator led lighting All-plastic design can withstand voltage 4000V, no risk of glass broken, single-ended contact power design, the distance of 2 lamp foot pin 15mm (6.5mm is safe distance), the input end can be achieved triple insulation.
The freezer led lighting has features like no gap between Light body and PCB board, good heat dissipation channel. In freezer test, the surface temperature does not exceed 35 degrees, the temperature inside the light does not exceed 45 degrees, heat dissipation is no problem.
ONN X08B cooler led lighting is energying saving.
Onn X08B refrigerator led lighting has a high CRI≥80.
Onn X08B Freezer led lighting has Strict quality control, 24 hrs aging test, stable quality of light.
Cooler led lighting Applications:
Lighting for freezer/refrigerator/cooler, cabinet, showcase, jewelry case and so on.
High CRI, make the objects more realistic, better lighting effect, increase the attractiveness of your products.
Comparison between ONN X08B and traditional T8/T5 Tube
1.Good heat dissipation
T8/T5 Tube: the traditional T8/T5 tube doesn’t have a much specified technical requirement, low grade of anti moisture. Long time working may not lead to problems, but when turn off, moisture will invade for thermal expansion, led chips will be broken, and thus leading to short life span. Traditional T8/T5 tube also has a hidden danger of 220V electric leakage.
ONN-X08B: in normal temperature test, X08B’s highest temperature cannot reach to 45 ℃. If used in refrigerator, the temperature can reduce 15-20℃,that means our X08B has an excellent performance on heat dissipation.
2.Fully enclosed
T8/T5 Tube: glass material, fragile. Glass debris will harm equipment, especially in food cabinet, glass lighting is forbidden. The electric pin on both ends design has a risk of being splashed by water. So T8/T5 only meet requirement of common illumination without water.
ONN-X08B: we adopt environmental friendly PC material and single-end input design which is universal in EU. The distance of two lamp pin is 15mm (6.5mm is safe distance). X08B is manufactured according to Europe quality, seal the both ends with waterproof glue, protection grade can reach to IP67, which T8 can’t reach. ONN-X08B is specially designed for cooler illuminations.
3.Product quality
T8/T5 Tube: belong to low pressure gas light, has an unknown life time. Luminous efficiency is only 70Lm/W, CRI is around 70. Wire terminal should be installed on cabinets, installation process is complex, need pins connection, unknown safe coefficient.
ONN-X08B: adopt 2835 LED for lighting, luminous efficiency can reach to 94Lm/W, CRI≥83, 50000h life span, if light up 24 hours per day, the life time can reach to five years, so ONN-X08B is a real long life and high brightness freezer led lighting!
Products of ONN LED Freezer Light Series for your choice
Company View:
Lighting Fair:
Company Activity:
Contact information:
SHENZHEN ONN SEMI-CONDUCTOR LIGHTING CO.,LTD
ADDRESS: 3F, SECOND ZONE, HAOFENG INDUSTRIAL PARK,
FUYONG XINHE, BAOAN DISTRICT, SHENZHEN, CHINA.
SKYPE: onnled
EMAIL: onn016@onnled.net
CELL PHONE: +86-13543317661
TELEPHONE: +86-755-36631969
